Sand Blasting Nozzle

A Sandblasting Nozzle life is a quite hard for one to prognosticate precisely because of the various traits such as the wide variety of grit being used, their dimensions and sizes, their distinctive configuration, their hardness, changing pressure arriving at the sandblasting nozzle, The Sandblasting nozzle tips bore area and sandblasting nozzle orifice diameter through blast hose life, ways of abrasive media cut-off. Grit blasting Nozzle size is of modifying shapes used to blast various models on the blasting surface.

Sand Blasting Nozzle for Sale

When choosing a sand blasting nozzle for sandblasting, there should be a balance to be held in mind, and it begins with our reciprocating and screw compressor. Once we know how the shape and size of our reciprocating and screw compressor for shot blasting nozzle air consumption influences production capacities, then we will study at tungsten carbide nozzle size. T.C. Nozzles reduce the Sand Blasting Machine Price in India and all countries so manufacturing cost automaticaly decreases.

Sand Blasting Nozzle Manufacturer

We are the largest sand blasting nozzle manufacturer in India at a low price. The price of the Sandblasting Nozzle depends on the material mixture because sandblast nozzle is available in Ceramic Nozzle, Tungsten carbide nozzle, Boron Carbide Nozzle. The larger the air quantity compressed / min, the more important is the pressure created at the Shot blasting nozzle. This improvises the generation rate in two ways:

• High pressure raises the speed of grit particles, giving more K.E. upon the surface blasting, giving a deeper grip design. This enables us to do a finer grade of grit, which provides more impacts per volume on blasting surfaces.
• More air volume enables us to use a larger bore of the nozzle for sandblasting, which lets us put more grit material on an objective surface.

Types of Sand Blasting Nozzle

The next problem is the sandblasting nozzle size & shape. Shot blasting nozzle types are mainly two forms straight bore and venturi nozzle, venturi Grit blasting nozzle is of multiple sizes and with various different patterns. Finally, we want to consider the material from which the nozzle is constructed of. The 3 chief factors in choosing the perfect Shot blasting nozzle for shot blasting bore material are strength, collision protection, and cost.

Grit Blasting Nozzle

For grit blasting, the most commonly used grit blasting nozzle orifice sizes range from 3/8 inch inside diameter to 3/4 inch expanding by increments of 1/16 inch. An 8 mm grit blasting nozzle is created to make pressure at 115 CFM air compressor. A 10 mm sandblasting nozzle is enough to generate an effective blasting pressure at a 209 CFM air compressor.

That’s necessary to remark that when we increase the diameter of the hole, we quadruple the area of the hole and the amount of air and grit that can pass through the grit blasting nozzle.

To find our optimally productive shot blasting nozzle, determine what nozzle pressure (PSI) we require to prepare for fertile blasting, and shot blasting nozzle air using or what amount of air our available air compressor can supply per min. (CFM).

Abrasive Blasting Nozzle

Abrasive Blasting Nozzle is of two basic shapes: a). straight & b). Venturi bore, with many modifications of venturi sandblasting nozzle.

Straight Bore sand Blasting Nozzle

A high pressurized air enters the left end of a straight bore sandblasting nozzle it accelerates, accelerating the grit particles dissolved in the flow. These grit particles exit the nozzle in a tight stream & create a narrow, intense blasting pattern upon the collision surface.

Venturi Nozzle Sandblasting Nozzle

a). Blasting Pattern: three inches at eighteen-inch distance
b). Production Rate:  4.6/5

Venturi Sandblasting Nozzle has a converging entry & a diverging exit. This shape is designed to produce an effect that greatly accelerates the airflow and grit particles.

The Venturi effect is an observation that when an airflow stimulates while moving through a system, there is a corresponding drop in pressure level.

Besides providing great acceleration, the angled shape shot blasting nozzle of the diverging end spreads out the flow, creating a huge blasting pattern & a more consistent particle distribution than a regular bore sandblasts nozzle.

Long Venturi sandblast nozzles give up to 4% greater production rates and consume less grit compared to straight bore nozzles.

Double Venturi Shot Blasting Nozzle

a). Blast Pattern: 3 inches at an 18-inch distance
b). Production Rate: 4-5

A double Venturi shot blast nozzle is with an extra-wide exit opening and holes at the diverging end.

According to the Venturi effect, as the velocity of the flow increases, the pressure drops, creating a vacuum between the shockwave and the throat, reducing abrasive material velocity. With a double Venturi type nozzle, atmospheric air is inserted through the holes into the low-pressure area, expanding the airflow to produce a huge blast pattern on the blast surface.

Wide Throat Shot Blasting Nozzle

a). Blast Pattern: 3 inches @ 18-inch distance
b). The Rate of Production: 5/5

Wide throat nozzles are a wide throat and an extra-1/4″ wide converging section. When used in coincidence with a hose pipe with matching inside diameter (and with a corresponding air volume increase), the wide throat nozzle can improve productivity level up to 15% over a long Venturi nozzle.

Sand Blasting Nozzle Manufacturers in India

Airo Shot Blast is one of the best sand blasting nozzle manufacturers in India. we have best portfolio of sand blasting nozzle and spare parts of sand/shot blasting machine. we also provide sand blasting machine, shot blasting machine, grit blasting machine, thermal spray gun & abrasives with best quality. we provide all the spare parts of sand blasting machine at low price.
