Table Shot Blasting Machine

A table shot blasting machine is an industrial solution for cleaning, descaling, deburring, and surface preparation of castings, forgings, aluminium parts, and heavy components. Its rotating turntable provides consistent abrasive coverage for components that are difficult to process in conveyor or tumbler blast machines. Airo Shot Blast Equipment manufactures and supplies table type shot blasting machines in customized configurations based on component size, weight, production capacity, and blasting requirements. Contact us for machine specifications, price, customization, and a commercial quotation.

What Is a Table Shot Blasting Machine?

A table shot blasting machine uses a turntable, the machine's core component, to move workpieces through the blast zone for cleaning and descaling. For asymmetrical components, the turntable can be set at different angles alongside multiple blast wheels, adapting the same basic mechanism to irregular part shapes.

We build both single and double-turntable configurations, and mobile-turntable machines that reduce processing time by allowing new components to be loaded while others are still being processed.

Types of Table Shot Blasting Machines

Swing Table Blasting Machine

A swing table blast machine has a rotary table divided into two sections: an external loading/unloading area and a shot blasting room. Workpieces are loaded by hand or via an automated handling system, and the table swings 180° to move them into the blast chamber, rotating throughout the blasting cycle. This design lets one station load and unload while the opposite station blasts, cutting idle equipment time significantly.

Available in single-door and double-door configurations, swing table machines suit heat-treated components, castings, and forgings, and are commonly used ahead of rubberizing and powder coating.

Rotary Table Blast Machine

A rotary table blast machine is divided into multiple chambers, with satellite loading positions at the front for easy loading and unloading of finished and raw jobpieces. After loading, the machine indexes forward by one station; individual job holders are separated by walls forming distinct chambers, and one chamber is dedicated to a blow-off station that removes residual blast media from finished parts before unloading.

The rotating table itself is built from solid manganese steel plates, available in various diameters, with a stack of blast turbines positioned for efficient, high-speed abrasive delivery. Dust emissions are filtered to under 3 mg/m³, and operation is controlled through a PLC control panel.

Key Features of Shot Blasting Machine

• Excellent for cleaning and descaling aluminium castings
• Two hardened shot blasting wheels for extended service life
• Compact footprint - requires less installation space than conveyor or tumblast shot blasting machine alternatives
• Easily integrated into existing production lines
• Strong ROI from day one of installation
• Effective for rust and heat scale removal
• Suited to shot peening and deburring applications​

Table Shot Blasting Machine Price

Table shot blasting machine price ranges from ₹4 lakh to ₹80 lakh, depending on type (swing table or rotary table type shot blasting machine), size, and number of blast wheels. Our table type shot blasting machine price is low compared to others.

Why Buy From Table Blast Machine Airo Shot Blast Equipments?

We've manufactured blasting equipment in Jodhpur since 2008 - 18 years, 8,000+ units installed, 25+ countries served. On table type shot blasting machine specifically:

• Both swing table and rotary table configurations available, matched to your part shape and volume.
• Manganese steel rotary tables and hardened blast wheels for long service life under continuous production.
• Three-step quality check on every machine before dispatch.
• ISO-certified manufacturing with export documentation handled in-house for international orders.

We are the leading table shot blasting machine manufacturer in India and also table blasting machine supplier worldwide. We also offer abrasive blasting machine, sand blasting machine, portable shot blasting machine, grit blasting machine, internal pipe blasting machine, granite engraving machine, steel shot, steel grit, plastic abrasive media etc.
